Discover premium Korean tractor parts at Diamond R Equipment. From OEM to aftermarket solutions, we carry engine, hydraulic, and maintenance components for reliable performance. Enjoy fast shipping and expert support to keep your tractor running strong.
Description: The MT4 features a variety of configurations enabling you to find the exact configuration you need. A ROPS and Cab version are available with highly featured operator platforms/cabs. The ergonomic design provides all-day comfort, as the robust frame provides high-capacity front loader and three point lift. Specification: Bucket Size: 78 inches Maximum Lift Height: 116.3 inches Clearance with Attachment Dump: 84.7 inches Reach at Maximum Height: 6.6 inches Maximum Dump Angle: 71 degrees Maximum Rollback Angle: 48 degrees Digging Depth: 4.1 inches Overall Height in Carry Position: 67.6 inches Lift Capacity (at Pivot Pin): 2,739 lbs Breakout Force (at Pivot Pin): 4,556 lbs Approximate Weight (Loader without Bucket): 1,014 lbs Width Weight Height Length 0 Inch 0 Gram 0 Inch 0 Inch
Description: Specifications: Tractor Application: MT5 Series Bucket Size (in): 78 Maximum Lift height (in): 126.5 Clearance with Attachment Dump (in): 95.3 Reach at Maximum Height (in): 5.7 Maximum Dump Angle (deg.) 64 Maximum Rollback Angle (deg.): 38 Digging Depth (in): 7.0 Overall Height in Carry Position (in): 64.2 Lift Capacity(@ Pivot pin, 1.5m) (lbs.) 3,364 Breakout Force(@ Pivot pin) (lbs.): 4,644 Approx. Weight(Loader w/o Bucket)(lbs.): 1,232 Width Weight Height Length 345 Kilograms 0 Inch
Description: Perfect cut with the LM1160 mower from LS Tractor The LM1160 mower has a durable structure, and the efficient operation of the device is possible thanks to the use of the best materials and technological solutions. The machine allows for high cutting quality, has few failures, and operates exceptionally quietly. The maintenance mower is lowered and raised hydraulically. The cutting height is adjustable using a knob, allowing you to select the appropriate operating parameters for the terrain. To protect against uneven terrain, the mower is equipped with support wheels that prevent it from being damaged. The most important features: cutting width: 1521 mm, total width: 1921 mm, weight: 129 kg, number of knives: 3 pcs, maximum knife revolutions: 2650 rpm, cutting height adjustment: 4 ranges. gear: 1:1.06, Specifications: State New Equipment Maintenance mower Tractor Models LS MT1.22 LS MT125 Working Width 1521 mm Working Height 25 - 102 mm Number of Knives 3 Dimensions Length: 1014 mm Height: 276 mm Width: 1921 mm Weight 129 kg Bevel Gear Ratio 1.06 Width Weight Height Length 0 Inch 0 Gram 0 Inch 0 Inch
Description: The MT225E Series is a high-value and feature rich compact utility tractor. Featuring high-capacity front-loader and three-point hitch is only the start of what this tractor series provides. Additional deluxe features like an electric engaged Independent PTO come standard. Specifications: Engine Type: 3 Cylinder, liquid-cooled, Diesel, NA, IDI Model (Tier 4): Mitsubishi S3L2 Engine HP (Gross): 24.6 PTO HP: 19.2 Rated Speed (RPM): 2,500 Displacement (cu. in.): 80.4 Fuel Tank Capacity (gal): 7.4 Alternator (V-A): 12 – 50 Drive Train Transmission: Synchrony shuttle No. of Speeds: F12 x R12 Brakes: Wet, Multi Disc Steering: Hydrostatic Power Steering PTO Type: Independent Rear (rpm): Standard (540) Hydraulic System Control System: Position Implement pump (gpm): 7.9 Steering pump (gpm): 4.6 Total flow (gpm): 12.5 Category, 3 pt hitch: CAT 1 Hitch Lift Capacity (lb): 1,808 Remote Valves: Option Dimension Overall Length, Frame to Link (in.): 118 Wheelbase (in.): 66 Overall Width with Tires (in.): 54 Height to Top of ROPS (in.): 88 Tire Size Ag Front/Rear: 7 – 14 / 11.2 – 24 IND Front/Rear: 25 x 8.5 – 14 / 43 x 16 – 20 Turf Front/Rear: 25 x 8.5 – 14 / 41 x 14 – 20 Weight Total Weight without Ballast (lbs.): 2,434 Width Weight Height Length 0 Inch 2434 Pounds 0 Inch 0 Inch
Description: Specifications: ENGINE: Type: 3 Cylinder, Liquid-cooled, Diesel, Naturally Aspirated (NA), Indirect Injection (IDI) Model (Tier 4): MHI Gross Engine HP: 24.6 hp PTO HP: 19.2 hp Rated Speed (RPM): 2,500 RPM Displacement: 80.4 cubic inches Fuel Tank Capacity: 10.6 gallons Alternator: 12V – 50 Amps DRIVE TRAIN: Transmission Type: Synchro Shuttle Number of Speeds: F12 X R12 (12 Forward, 12 Reverse) Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO (Power Take-Off): Type: Independent Rear PTO Speed: 540 RPM (Standard) HYDRAULIC SYSTEM: Control System: Position Implement Pump Flow: 7.9 gallons per minute (gpm) Steering Pump Flow: 4.6 gpm Total Flow: 12.5 gpm 3-Point Hitch Category: Category I (CAT I) Hitch Lift Capacity at Hitch End: 1,808 lbs Remote Valves: Optional DIMENSIONS: Overall Length (Frame to Link): 119 inches Overall Width with Tires: 66 inches Wheelbase: 66 inches Height to Top: 95 inches TIRE SIZES: Agricultural (Ag) Front / Rear: 7 – 14 / 11.2 – 24 Industrial (IND) Front / Rear: 27X8.50-15 / 43X16.00-20 Versa Turf (VT) Front / Rear: 27X8.50-15 / 43X16.00-20 Turf Front / Rear: 25X8.50-14 / 41X14.00-20 WEIGHT: Total Weight without Ballast: 2,985 lbs Width Weight Height Length 2985 Pounds 0 Inch
Description: Specifications: Engine Type: 3 Cylinder, Liquid-Cooled, Diesel, Naturally Aspirated (NA), Common Rail Direct Injection (CRDI) Model (Tier 4): YANMAR Gross Engine HP: 31.7 PTO HP: 28.5 Rated Speed (RPM): 2,600 Displacement (cu. in.): 100.2 Fuel Tank Capacity (gal): 10.6 Alternator Voltage-Amperage: 12V – 55 Amps Drive Train Transmission Type: Synchro Shuttle Number of Speeds: 12 Forward x 12 Reverse Brakes: Wet, Multi-Disc Steering: Hydrostatic Power Steering PTO (Power Take-Off) Type: Independent Rear PTO Speed: 540 rpm (Standard) Hydraulic System Control System: Position Control Implement Pump Flow (gpm): 7.4 Steering Pump Flow (gpm): 5 Total Flow (gpm): 12.4 3-Point Hitch Category: CAT I Hitch Lift Capacity (lbs.): 1,808 Remote Valves: Option available Dimensions Overall Length (Frame to Link) (in.): 125 Overall Width with Tires (in.): 66 Wheelbase (in.): 69 Height to Top (in.): 95 Tire Sizes Ag Tires (Front / Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front / Rear): 27 x 8.50 - 15 / 43 x 16.00 - 20 Turf Tires (Front / Rear): 25 x 8.50 - 14 / 41 x 14.00 - 20 Weight Total Weight (without ballast): 3,166 lbs Width Weight Height Length 3166 Kilograms 0 Inch
Description: Features: Redesigned air conditioning and roof configuration, providing additional head space and increased forward visibility Much improved seat comfortability Cruise control & linked pedal functionalities (Engine RPM matches user input demand on F/R HST pedals) New hood design (LS Family look), Grill open space plus 20% LED head Lamp 1 Inch large tire size and four different tire options Larger lifting capacity, loader lifting capacity of New MT226E (LL3301/2) 1,965 lbs. New MT2E & MT2 (LL3303) 2,506lbs. Workability, 4-point mount structure as well as digging depth of 97.2” and bucket digging force of 3,663lbs. TF-LCD instrument panel providing various information like, regen time, oil change interval, etc. E/G RPM interlocking switch (STD). When working at low RPM, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/lift. Specifications: Type: 3 Cylinder Liquid-cooled Diesel, NA, CRDII Model (Tier 4): YANMAR Engine HP (Gross): 31.7 HP PTO HP: 26.2 HP Rated Speed: 2,600 RPM Displacement: 100.2 cu in Fuel Tank Capacity: 10.6 gal Alternator: 12V – 50 Amps Drive Train Transmission Type: HST (Hydrostatic Transmission) Number of Speeds: 3 Ranges Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO Type: Independent Rear RPM: 540 (Standard) Hydraulic System Control System: Position Implement Pump: 6.7 gpm Steering Pump: 5 gpm Total Flow: 11.7 gpm 3-Point Hitch Category: CAT I Hitch Lift Capacity: 1,808 lbs Remote Valves: 1 Pair Dimensions Overall Length (Frame to Link): 125 in Overall Width (with Tires): 66 in Wheelbase: 69 in Height to Top: 95 in Tire Sizes Ag Tires (Front/Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Versa Turf Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Turf Tires (Front/Rear): 25 x 8.50 – 14 / 41 x 14 – 20 Weight Total Weight (without ballast): 3,254 lbs Width Weight Height Length 3254 Kilograms 0 Inch
Description: Redesigned air conditioning and roof configuration, providing additional head space and increased forward visibility Much improved seat comfortability Cruise control & linked pedal functionalities (Engine RPM matches user input demand on F/R HST pedals) New hood design (LS Family look), Grill open space plus 20% LED head Lamp 1 Inch large tire size and four different tire options Larger lifting capacity, loader lifting capacity of New MT226E (LL3301/2) 1,965 lbs. New MT2E & MT2 (LL3303) 2,506lbs. Workability, 4-point mount structure as well as digging depth of 97.2” and bucket digging force of 3,663lbs. TF-LCD instrument panel providing various information like, regen time, oil change interval, etc. E/G RPM interlocking switch (STD). When working at low RPM, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/lift. Specifications: ENGINE Type: 3 Cylinder, Liquid-cooled Diesel, Naturally Aspirated (NA), Common Rail Direct Injection (CRDI) Model (Tier 4): YANMAR Engine HP (Gross): 31.7 hp PTO HP: 26.2 hp Rated Speed: 2,600 RPM Displacement: 100.2 cu. in. Fuel Tank Capacity: 11.4 gallons Alternator: 12V – 55 Amps DRIVE TRAIN Transmission Type: Hydrostatic (HST) Number of Speeds: 3 Ranges Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO (Power Take-Off) Type: Independent Rear PTO Speed: 540 RPM (Standard) HYDRAULIC SYSTEM Control System: Position Implement Pump Flow: 6.7 gpm Steering Pump Flow: 5 gpm Total Hydraulic Flow: 11.7 gpm 3-Point Hitch Category: CAT I Hitch Lift Capacity: 1,808 lbs Remote Valves: 1 Pair DIMENSIONS Overall Length (Frame to Link): 125 inches Overall Width with Tires: 66 inches Wheelbase: 69 inches Height to Top of ROPS: 90 inches TIRE SIZE OPTIONS Agricultural Tires (Front/Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Versa Turf Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Turf Tires (Front/Rear): 25 x 8.50 – 14 / 41 x 14.00 – 20 WEIGHT Total Weight (without ballast): 3,721 lbs Width Weight Height Length 3721 Pounds 0 Inch
Description: Specifications: Engine Type: 4-cylinder, liquid-cooled, Diesel, CRDI, NA Model (Tier 4): YANMAR Engine HP (Gross): 42.5 HP PTO HP: 35.4 HP Rated Speed: 2,600 RPM Displacement: 133.6 cu. in. Fuel Tank Capacity: 10.6 gal Alternator: 12V – 55 Amps Drive Train Transmission Type: Synchro Shuttle Speeds: F12 x R12 Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO Type: Independent Rear RPM: 540 (Standard) Hydraulic System Control System: Position Implement Pump: 7.4 gpm Steering Pump: 5.0 gpm Total Flow: 12.4 gpm 3-Point Hitch Category: CAT I Hitch Lift Capacity: 1,808 lbs Remote Valves: Optional Dimensions Overall Length (Frame to Link): 125 in. Overall Width (with Tires): 66 in. Wheelbase: 74 in. Height to Top: 95 in. Tire Sizes Ag Tires (Front / Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front / Rear): 27x8.50-15 / 43x16.00-20 Turf Tires (Front / Rear): 25x8.50-14 / 41x14.00-20 Weight Total Weight (without ballast): 3,250 lbs Width Weight Height Length Kilogram 0 Inch
Description: Specifications: Engine Type: 4-Cylinder, Liquid-Cooled Diesel, Naturally Aspirated, Common Rail Direct Injection (CRDI) Model (Tier 4): YANMAR Engine Horsepower (Gross): 42.5 HP PTO Horsepower: 34.8 HP Rated Speed: 2,600 RPM Displacement: 133.6 cu. in. Fuel Tank Capacity: 11.4 gallons Alternator: 12V – 55 Amps Drive Train Transmission Type: Hydrostatic Transmission (HST) Number of Speeds: 3 Ranges Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO (Power Take-Off) Type: Independent Rear PTO Speed: 540 RPM (Standard) Hydraulic System Control System: Position Implement Pump Flow: 6.7 gpm Steering Pump Flow: 5.0 gpm Total Flow: 11.7 gpm 3-Point Hitch Category: CAT I Hitch Lift Capacity (at Hitch End): 1,808 lbs Remote Valves: 1 Pair Dimensions Overall Length (Frame to Link): 125 in. Overall Width with Tires: 66 in. Wheelbase: 74 in. Height to Top: 90 in. Tire Size Ag Tires (Front/Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Versa Turf Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Turf Tires (Front/Rear): 25 x 8.50 – 14 / 41 x 14.00 – 20 Weight Total Weight without Ballast: 3,805 lbs Width Weight Height Length 3805 Kilograms 0 Inch
Description: The MT4 features a variety of configurations enabling you to find the exact configuration you need. A ROPS and Cab version are available with highly featured operator platforms/cabs. The ergonomic design provides all-day comfort, as the robust frame provides high-capacity front loader and three point lift. Specifications: Engine Type: Vertical, water-cooled, 4-cycle diesel engine Model (Tier 4): L4C25-T Gross Engine HP: 68 HP PTO HP: 60 HP Rated Speed: 2,500 RPM Displacement: 152.8 cu. in. Fuel Tank Capacity: 21.1 gallons Alternator: 12V – 70A Drive Train Transmission: Synchro Shuttle / Power Shuttle No. of Speeds: F16 x R16 Brakes: Wet, multi-disc Steering: Hydrostatic power steering PTO Type: Independent Rear PTO Speed: 540 RPM Hydraulic System Control System: Position/Draft Implement Pump Flow: 9.9 GPM Steering Pump Flow: 4.6 GPM Total Hydraulic Flow: 14.5 GPM 3-Point Hitch Category: CAT II Hitch Lift Capacity: 4,079 lbs Remote Valves: 2 pairs (Front), 2 pairs (Rear) (1 detent, 1 standard) Dimensions Overall Length with 3-Point Hitch: 138.6 in. Wheelbase: 80.3 in. Minimum Overall Width with Ag Tires: 70 in. Height to Top of Cab with Ag Tires: 103 in. Tire Sizes Agricultural (Front/Rear): 9.5 – 20 / 16.9 – 24 Industrial (Front/Rear): 10.5/80 – 18 / 19.5L – 24 Weight Total Weight without Ballast: 4,674 lbs Width Weight Height Length 4380 Kilograms 0 Inch
Description: The MT3 Series provides four different horsepower models featuring both cab and ROPS options. These models are available with gear drive or hydrostatic transmissions. All models feature an ergonomic design making this a truly premium tractor. Specifications: Engine Type: 3-Cylinder, Liquid-Cooled, Diesel, Turbocharged, Common Rail Direct Injection (CRDI) Model (Tier 4): L3C19-T Engine Horsepower (Gross): 42 HP PTO Horsepower: 35.7 HP (Hydro) / 33.6 HP (Gear) Rated Speed: 2,600 RPM Displacement: 114.7 cu. in. Fuel Tank Capacity: 12.4 gallons (Cabin) / 10.6 gallons (ROPS) Alternator: 12V – 70 Amps Drive Train Transmission: Synchro Shuttle / Hydrostatic Transmission (HST) Number of Speeds: F16 x R16 (Gear) / 3 Ranges (HST) Brakes: Wet, Multi-Disc PTO (Power Take-Off) Type: Independent Rear PTO Speed: 540 RPM Hydraulic System Control System: Position/Draft Implement Pump Flow: 8.2 gpm Steering Pump Flow: Gear: 4.1 gpm Hydro: 5.5 gpm Hydro (Cab): 6.8 gpm Total Flow: Gear: 12.3 gpm Hydro: 13.7 gpm Hydro (Cab): 15.0 gpm 3-Point Hitch Category: CAT 1 Hitch Lift Capacity: 2,755 lbs Remote Valves: 2 Front, 2 Rear (1 Detent, 1 Standard) Dimensions Overall Length (Bumper to Link): 133 in. Wheelbase: 73.2 in. Overall Width with Tires: 62.5 in. Height to Top of ROPS: 95 in. (ROPS) / 90 in. (Cab) Tire Sizes Ag Tires (Front/Rear): 9.5 – 16 / 13.6 – 24 Industrial Tires (Front/Rear): 12 – 16.5 / 17.5L – 24 Turf Tires (Front/Rear): 28 x 8.5 – 15 / 41 x 14 – 20 Weight Total Weight Without Ballast: 3,935 lbs (ROPS) / 4,446 lbs (Cab) Width Weight Height Length 3869 Kilograms 0 Inch
When it comes to finding parts for specific tractor models, you've got a range of options to ensure your equipment runs smoothly. Here's a detailed list of the models for which parts are readily available:
This lineup ensures that whether you're dealing with compact utility tasks or demanding agricultural operations, there are parts available to keep any of these models up and running efficiently.
When it comes to ordering the right tractor parts, compatibility with your specific model and year is crucial. Here's how you can make the right choice:
Start by carefully identifying the model of your tractor. Look for parts that include a detailed list of compatible tractor models. This information is usually clearly stated to help you determine if a part will fit your machine.
Pay close attention to any specific years that are mentioned. Some parts are designed for certain model years due to design tweaks and changes made by manufacturers. Ensuring that your tractor's year matches those listed can prevent compatibility issues.
Most part listings include a 'Fits Models' section. This list is invaluable for making sure you're selecting a part that will seamlessly integrate with your tractor.
If you’re unsure, consult a professional or a trusted dealer. They can offer expert advice and may even have access to cross-reference systems that can confirm part compatibility.
Before finalizing your order, double-check the model and year once more to ensure everything aligns. This simple step can save you from unnecessary hassle and return processes.
Following these steps will help you select the right parts the first time, ensuring your tractor remains in top working condition without unnecessary delays.
