Description
Description:
Tackle Tough Conditions
Woods Exclusive tiller blade mounting feature keeps blades from coming loose in the field. Heat-treated, C-shaped tines penetrate deep, even in thick residue and loose, compacted or rocky soil.
Optimize Your Seed Bed
Every Woods tiller can be factory configured
to forward or reverse rotation to best match your planting application, save time, and optimize your seedbed.
Unmatched Gearbox PROTECTION
6-year warranty including parts, labor, and seals.
Features:
- Engineered Quick-Hitch Ready from the factory. No additional hardware is required to use your quick hitch, so you can get in the field and get to work.
- Robust Gear-Driven Side Drive provides years of reliable service and requires far less maintenance than chain-driven units.
- Tapered Tailgate removes furrow for a finished seedbed.
- Fixed Offset Tiller Width covers tire tracks with each pass.
- Adjustable Skid Shoes provide easy depth control.
Specifications:
- Product Tier: Professional
- Tractor PTO HP: 20-50
- Tractor Hitch: CAT 1
- Working Width: 71 in
- Overall Width: 81 in
- Weight: 621 lbs
- Maximum Tilling Depth: 7 in
- Drive Type: Gearbox
- Number of Tines / Number of Flanges: 36 / 9
- Number of Tines per Flange: 4 C-type
- Rotor Speed: 210 rpm
- Tractor PTO Speed: 540 rpm
- PTO Driveline Protection: Slip clutch
- Gearbox Housing: Heavy-duty cast iron
- Gearbox Drain Plug: Yes
- Quick-hitch Compatible: Yes
- Parking Stand: Standard
- Woods C®: Compact/Subcompact
- Gearbox Warranty: 6 years
| Width |
Weight |
Height |
Length |
| 0 Inch |
621 Pounds |
0 Inch |
0 Inch |
