Description
Description:
Greater Durability
Woods Exclusive Z-shaped, high-strength steel bumper is twice as thick as competitive models for backing over tough brush.
Easy Maintenance
EZ-Change™ Blade System allows blade change in five steps with a 3/4″ wrench. No impact gun or torch required.
Easy Connection
Quick-Hitch Ready from the factory. No additional hardware is needed to use your quick hitch.
Unmatched Gearbox PROTECTION
10-year warranty including parts, labor, and seals.
Additional Features
- Quick-Hitch Ready from the factory. No additional hardware is needed to use your quick hitch.
- Adjustable Driveline Holder holds the driveline as you prepare to connect or disconnect the cutter.
- Tapered Front gives you more room between the tractor tire and cutter when connecting and disconnecting to the tractor.
- Woods Exclusive Z-shaped, high-strength steel bumper is twice as thick as competitive models for backing over tough brush.
- Large Blade Access Window for quick and easy blade maintenance from the top of the deck.
- Deep Cutting Deck works together with high-lift blades and a unique rear baffling design for better cut quality.
- Skid Shoes protect the deck and are easy to change. Adjust the height on heavy-duty models.
- A Heavy-Duty Crossbar and ¼” steel stump jumper to protect the undercarriage in extreme conditions.
- A Full Frame Design with full-length, 3 x 3″ tubes and channels for greater strength and durability.
- Stress Points Tied To The 3 X 3″ Tubes (Not The Deck Plate) for added stability.
- Rear Baffle, Standard On All Models, concentrates the airflow and ensures cut material is distributed evenly.
- Large 1/2-Inch By 4-Inch Blades And Extra Deep Deck precisely cut large amounts of material.
Specifications:
-
Product Tier: Professional
-
Tractor PTO RPM: 540 (HP: 40-90)
-
Hitch Compatibility: CAT 1 / CAT 2 clevis
-
Adjustable Cutting Height: 12" - 2"
-
Cutting Capacity Diameter: 2"
-
Cutting Width: 84"
-
Blade Tip Speed: 15,086 fpm
-
Blade Size: 0.50 x 4 in
-
Blade Carrier: Oval stump jumper
-
Deck Thickness: 0.120 in (11 ga)
-
Side Frame Depth / Thickness: 11.4 in / 0.135 in
-
Frame and Deck Support: 3 x 3 tubes
-
Weight with Chain Shielding: 1,132 lbs
-
Transport Width: 91.3 in
-
Output Shaft Diameter: 1.57 in
-
Overall Length: 124 in
-
Deck Construction: Smooth top, sloped
-
Gearbox HP: 90
-
Quick-hitch Compatible: Yes
-
Driveline Protection: Slip-clutch
-
Skid Shoes: Full-length, replaceable
-
Rear Bumper: Z-channel
- Options Available:
- Rubber belting/steel band or chain shielding
- Check chains
- Dual tailwheel
-
Gearbox Warranty: 10 year limited
-
Structure Warranty: 2 years
