| ENGINE |
|
| Type |
3 Cylinder, liquid-cooled, Diesel, NA, IDI |
| Model (Tier 4) |
Mitsubishi S3L2 |
| Engine HP (Gross) |
24.6 |
| PTO HP |
19.2 |
| Rated Speed (RPM) |
2,500 |
| Displacement (cu. in.) |
80.4 |
| Fuel Tank Capacity (gal) |
7.4 |
| Alternator (V-A) |
12 – 50 |
| DRIVE TRAIN |
|
| Transmission |
Synchro shuttle |
| No. of Speeds |
F12 x R12 |
| Brakes |
Wet, Multi Disc |
| Steering |
Hydrostatic Power Steering |
| PTO |
|
| Type |
Independent |
| Rear (rpm) |
Standard (540) |
| HYDRAULIC SYSTEM |
|
| Control System |
Position |
| Implement Pump (gpm) |
7.9 |
| Steering Pump (gpm) |
4.6 |
| Total Flow (gpm) |
12.5 |
| Category, 3 pt hitch |
CAT 1 |
| Hitch Lift Capacity (lb) |
1,808 |
| Remote Valves |
Option |
| DIMENSION |
|
| Overall Length, Frame to Link (in.) |
118 |
| Wheelbase (in.) |
66 |
| Overall Width with Tires (in.) |
54 |
| Height to Top of ROPS (in.) |
88 |
| TIRE SIZE |
|
| Ag Front / Rear |
7 – 14 / 11.2 – 24 |
| IND Front / Rear |
25 x 8.5 – 14 / 43 x 16 – 20 |
| Turf Front / Rear |
25 x 8.5 – 14 / 41 x 14 – 20 |
| WEIGHT |
|
| Total Weight Without Ballast (lbs.) |
2,434 |
