Discover premium Korean tractor parts at Diamond R Equipment. From OEM to aftermarket solutions, we carry engine, hydraulic, and maintenance components for reliable performance. Enjoy fast shipping and expert support to keep your tractor running strong.
Description: Specifications: Type: 3 Cylinder Liquid-cooled Diesel, NA, CRDII Model (Tier 4): YANMAR Engine HP (Gross): 31.7 HP PTO HP: 26.2 HP Rated Speed: 2,600 RPM Displacement: 100.2 cu in Fuel Tank Capacity: 10.6 gal Alternator: 12V – 50 Amps Drive Train Transmission Type: HST (Hydrostatic Transmission) Number of Speeds: 3 Ranges Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO Type: Independent Rear RPM: 540 (Standard) Hydraulic System Control System: Position Implement Pump: 6.7 gpm Steering Pump: 5 gpm Total Flow: 11.7 gpm 3-Point Hitch Category: CAT I Hitch Lift Capacity: 1,808 lbs Remote Valves: 1 Pair Dimensions Overall Length (Frame to Link): 125 in Overall Width (with Tires): 66 in Wheelbase: 69 in Height to Top: 95 in Tire Sizes Ag Tires (Front/Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Versa Turf Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Turf Tires (Front/Rear): 25 x 8.50 – 14 / 41 x 14 – 20 Weight Total Weight (without ballast): 3,254 lbs Width Weight Height Length 3254 Kilograms 0 Inch
Description: Specifications: Engine Type: 3 Cylinder, Liquid-Cooled, Diesel, Naturally Aspirated (NA), Common Rail Direct Injection (CRDI) Model (Tier 4): YANMAR Gross Engine HP: 31.7 PTO HP: 28.5 Rated Speed (RPM): 2,600 Displacement (cu. in.): 100.2 Fuel Tank Capacity (gal): 10.6 Alternator Voltage-Amperage: 12V – 55 Amps Drive Train Transmission Type: Synchro Shuttle Number of Speeds: 12 Forward x 12 Reverse Brakes: Wet, Multi-Disc Steering: Hydrostatic Power Steering PTO (Power Take-Off) Type: Independent Rear PTO Speed: 540 rpm (Standard) Hydraulic System Control System: Position Control Implement Pump Flow (gpm): 7.4 Steering Pump Flow (gpm): 5 Total Flow (gpm): 12.4 3-Point Hitch Category: CAT I Hitch Lift Capacity (lbs.): 1,808 Remote Valves: Option available Dimensions Overall Length (Frame to Link) (in.): 125 Overall Width with Tires (in.): 66 Wheelbase (in.): 69 Height to Top (in.): 95 Tire Sizes Ag Tires (Front / Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front / Rear): 27 x 8.50 - 15 / 43 x 16.00 - 20 Turf Tires (Front / Rear): 25 x 8.50 - 14 / 41 x 14.00 - 20 Weight Total Weight (without ballast): 3,166 lbs Width Weight Height Length 3166 Kilograms 0 Inch
Description: Specifications: ENGINE: Type: 3 Cylinder, Liquid-cooled, Diesel, Naturally Aspirated (NA), Indirect Injection (IDI) Model (Tier 4): MHI Gross Engine HP: 24.6 hp PTO HP: 19.2 hp Rated Speed (RPM): 2,500 RPM Displacement: 80.4 cubic inches Fuel Tank Capacity: 10.6 gallons Alternator: 12V – 50 Amps DRIVE TRAIN: Transmission Type: Synchro Shuttle Number of Speeds: F12 X R12 (12 Forward, 12 Reverse) Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO (Power Take-Off): Type: Independent Rear PTO Speed: 540 RPM (Standard) HYDRAULIC SYSTEM: Control System: Position Implement Pump Flow: 7.9 gallons per minute (gpm) Steering Pump Flow: 4.6 gpm Total Flow: 12.5 gpm 3-Point Hitch Category: Category I (CAT I) Hitch Lift Capacity at Hitch End: 1,808 lbs Remote Valves: Optional DIMENSIONS: Overall Length (Frame to Link): 119 inches Overall Width with Tires: 66 inches Wheelbase: 66 inches Height to Top: 95 inches TIRE SIZES: Agricultural (Ag) Front / Rear: 7 – 14 / 11.2 – 24 Industrial (IND) Front / Rear: 27X8.50-15 / 43X16.00-20 Versa Turf (VT) Front / Rear: 27X8.50-15 / 43X16.00-20 Turf Front / Rear: 25X8.50-14 / 41X14.00-20 WEIGHT: Total Weight without Ballast: 2,985 lbs Width Weight Height Length 2985 Pounds 0 Inch
Description: The MT225E Series is a high-value and feature rich compact utility tractor. Featuring high-capacity front-loader and three-point hitch is only the start of what this tractor series provides. Additional deluxe features like an electric engaged Independent PTO come standard. Specifications: Engine Type: 3 Cylinder, liquid-cooled, Diesel, NA, IDI Model (Tier 4): Mitsubishi S3L2 Engine HP (Gross): 24.6 PTO HP: 19.2 Rated Speed (RPM): 2,500 Displacement (cu. in.): 80.4 Fuel Tank Capacity (gal): 7.4 Alternator (V-A): 12 – 50 Drive Train Transmission: Synchrony shuttle No. of Speeds: F12 x R12 Brakes: Wet, Multi Disc Steering: Hydrostatic Power Steering PTO Type: Independent Rear (rpm): Standard (540) Hydraulic System Control System: Position Implement pump (gpm): 7.9 Steering pump (gpm): 4.6 Total flow (gpm): 12.5 Category, 3 pt hitch: CAT 1 Hitch Lift Capacity (lb): 1,808 Remote Valves: Option Dimension Overall Length, Frame to Link (in.): 118 Wheelbase (in.): 66 Overall Width with Tires (in.): 54 Height to Top of ROPS (in.): 88 Tire Size Ag Front/Rear: 7 – 14 / 11.2 – 24 IND Front/Rear: 25 x 8.5 – 14 / 43 x 16 – 20 Turf Front/Rear: 25 x 8.5 – 14 / 41 x 14 – 20 Weight Total Weight without Ballast (lbs.): 2,434 Width Weight Height Length 0 Inch 2434 Pounds 0 Inch 0 Inch
Description: Perfect cut with the LM1160 mower from LS Tractor The LM1160 mower has a durable structure, and the efficient operation of the device is possible thanks to the use of the best materials and technological solutions. The machine allows for high cutting quality, has few failures, and operates exceptionally quietly. The maintenance mower is lowered and raised hydraulically. The cutting height is adjustable using a knob, allowing you to select the appropriate operating parameters for the terrain. To protect against uneven terrain, the mower is equipped with support wheels that prevent it from being damaged. The most important features: cutting width: 1521 mm, total width: 1921 mm, weight: 129 kg, number of knives: 3 pcs, maximum knife revolutions: 2650 rpm, cutting height adjustment: 4 ranges. gear: 1:1.06, Specifications: State New Equipment Maintenance mower Tractor Models LS MT1.22 LS MT125 Working Width 1521 mm Working Height 25 - 102 mm Number of Knives 3 Dimensions Length: 1014 mm Height: 276 mm Width: 1921 mm Weight 129 kg Bevel Gear Ratio 1.06 Width Weight Height Length 0 Inch 0 Gram 0 Inch 0 Inch
Description: Specifications: Engine Type: 3-Cylinder, Liquid-Cooled, Diesel, NA, CRDI Model (Tier 4): Yanmar Engine HP (Gross): 31.7 HP PTO HP: 26.2 HP Rated Speed: 2,600 RPM Displacement: 100.2 cu. in. Fuel Tank Capacity: 11.4 gallons Alternator: 12V – 55 Amps Drive Train Transmission Type: HST (Hydrostatic Transmission) Number of Speeds: 3 Ranges Brakes: Wet, Multi-Disc Steering: Hydrostatic Power Steering PTO Type: Independent Rear PTO Speed: 540 RPM (Standard) Hydraulic System Control System: Position Implement Pump Flow: 6.7 gpm Steering Pump Flow: 5 gpm Total Hydraulic Flow: 11.7 gpm 3-Point Hitch Category: CAT I Hitch Lift Capacity (at Hitch End): 1,808 lbs Remote Valves: 1 Pair Dimensions Overall Length (Frame to Link): 125 inches Overall Width with Tires: 66 inches Wheelbase: 69 inches Height to Top: 90 inches Tire Size Ag (Front / Rear): 7 – 14 / 11.2 – 24 Industrial (Front / Rear): 27X8.50-15 / 43X16.00-20 VT (Front / Rear): 27X8.50-15 / 43X16.00-20 Turf (Front / Rear): 25X8.50-14 / 41X14.00-20 Weight Total Weight without Ballast: 3,721 lbs Width Weight Height Length 273 Kilograms 0 Inch
Description: These quick-attach, skid-steer compatible front-end loaders have a higher lift capacity than the competition. And come standard with body-shielding grill guards. Specifications: Bucket (in.): 66 Maximum Lift height (in.): 94.3 Clearance with Attachment Dump (in.): 67 Reach at Maximum Height (in.): 14.4 Maximum Dump Angle (deg.): 48 Maximum Rollback Angle (deg.): 42.5 Digging Depth (in.): 4.8 Overall Height in Carry Position (in.): 51.2 Lift Capacity (Bucket Pivot Pin, MAX, Height) (lb.): 1,599 Lift Capacity (Pivot pin @ 1.5m) (lb.): 1,965 Breakout Force(@ Pivot pin) (lb.): 2,962 Approx. Weight (Loader w/o Bucket) (lb.): 741 Width Weight Height Length 0 Inch 0 Gram 0 Inch 0 Inch
Description: These quick-attach, skid-steer compatible front-end loaders have a higher lift capacity than the competition. And come standard with body-shielding grill guards. Specification: Maximum Lift Height (in.): 85.7 Clearance with Attachment Dump(in.): 65 Reach at Maximum Height (in.): 22 Maximum Dump Angle (deg.): 52 Maximum Rollback Angle (deg.): 43 Digging Depth (in.): 4.4 Overall Height in Carry Position (in.): 42.8 Lift Capacity (@ Pivot Pin) (lb.): 1,270 Breakout Force (@ Pivot pin) (lb.): 1,640 Approx. Weight (Loader w/o Bucket) (lb.): 638 GENERAL Lift Capacity 1,270 lb .Digging Depth 4.4 in .Maximum Lift Height 85.7 in. Weight 638 lb. Width Weight Height Length 0 Inch 638 Pounds 0 Inch 0 Inch
Description: The LS Tractor LB3001 backhoe is a powerful and precise digging attachment explicitly designed for compatibility with the LS Tractor MT226E model. This backhoe is perfect for various intensive digging, trenching, and backfilling tasks in agriculture, landscaping, and light construction, offering deep digging capabilities and substantial stability. Key Features: Digging and Operational Performance: Digging Depth: 97.2 inches, allowing for deep and practical excavation suitable for various applications. Reach from the Centerline of the Swing Pivot: 127.2 inches, providing extensive reach for versatile digging operations. Loading Height: 76.2 inches, facilitating easy loading and material handling. Swing Arc: 160 degrees, offering broad maneuverability for digging around obstacles. Bucket Rotation: 180 degrees, enabling precise material placement and efficient digging. Stability and Safety: Stabilizer Spread (Down Position): 67.5 inches, ensuring a stable base during operation. Stabilizer Spread (Up Position): 50 inches, compact for easy movement and storage. Bucket Digging Force: 3663 lbs, robust enough for harsh soil conditions and excavation tasks. Design and Construction: Transport Height: 81.1 inches, optimized for easy movement and transition between job sites. Compatibility: It is specifically engineered for seamless operation with the LS Tractor MT226E (ROPS), ensuring optimal performance and handling. Width Weight Height Length 0 Inch 0 Gram 0 Inch 0 Inch
Description: LB2100 TRACTOR EXCAVATOR FOR THE LS TRACTOR MT3 TRACTOR A mini tractor excavator mounted on a 3-point three-point hitch, Cat. I, is an ideal tool designed to work with LS MT3 series tractors. The design, size and weight of the excavator allow it to be used in situations where the operation of a large machine is impossible or when the terrain does not allow the use of heavier equipment. The LB2100 tractor excavator has a very durable construction. Thanks to it, we can not only perform deep excavations up to a maximum of 2280 mm, but also easily transport the load by lifting the arm to a height of up to 1840 mm. The completely hydraulically powered tractor excavator is equipped with opening stabilizers, an efficient hydraulic pump, and during work, the operator uses the tractor seat by turning it backwards. The maximum possible discharge of the LB2100 excavator with the bucket positioned at an angle of 60 degrees is 1,840 mm. SPECIFICATION: State New Mark LS Tractor Maximum digging depth (mm) 2280 Weight (kg) 485 loading height (mm) 1840 Bucket rotation angle (°) 160 Maximum arm reach (mm) 3180 Stabilizer span (mm) 1745 Width Weight Height Length 0 Inch 0 Gram 0 Inch 0 Inch
Description: Since they don't require removal of the lower 3-point hitch arms, our sub-frame mounted, quick-attach backhoes are time-savers even before you start digging in. Specification: Digging Depth (in.): 77.8 Reach from Centerline of Swing Pivot (in.): 144.9 Loading Height (in.): 59.6 Swing Arc (deg.): 140 Transport Height (in.): 74.7 Bucket Rotating (deg.): 169.4 Stabilizer Spread (Down Position) (in.): 78.6 Stabilizer Spread (Up Position) (in.): 53.2 Bucket Digging Force (lbs.): 2,097 Shipping Weight (lbs.): 873 Width Weight Height Length 0 Inch 0 Gram 0 Inch 0 Inch
Description: Specifications: Engine Type: 4 Cylinder liquid-cooled Diesel, NA, CRDI Model (Tier 4): YANMAR Engine HP (Gross): 42.5 HP PTO HP: 34.8 HP Rated Speed: 2,600 RPM Displacement: 133.6 cu in Fuel Tank Capacity: 10.6 gal Alternator: 12V – 55 Amps Drive Train Transmission Type: HST (Hydrostatic Transmission) Number of Speeds: 3 Ranges Brakes: Wet, Multi-disc Steering: Hydrostatic Power Steering PTO Type: Independent Rear RPM: 540 (Standard) Hydraulic System Control System: Position Implement Pump: 6.7 gpm Steering Pump: 5 gpm Total Flow: 11.7 gpm 3-Point Hitch Category: CAT I Hitch Lift Capacity: 1,808 lbs Remote Valves: 1 Pair Dimensions Overall Length (Frame to Link): 125 in Overall Width (with Tires): 66 in Wheelbase: 74 in Height to Top: 95 in Tire Sizes Ag Tires (Front/Rear): 7 – 14 / 11.2 – 24 Industrial Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Versa Turf Tires (Front/Rear): 27 x 8.50 – 15 / 43 x 16.00 – 20 Turf Tires (Front/Rear): 25 x 8.50 – 14 / 41 x 14 – 20 Weight Total Weight (without ballast): 3,338 lbs Width Weight Height Length 3338 Kilograms 0 Inch
When it comes to finding parts for specific tractor models, you've got a range of options to ensure your equipment runs smoothly. Here's a detailed list of the models for which parts are readily available:
This lineup ensures that whether you're dealing with compact utility tasks or demanding agricultural operations, there are parts available to keep any of these models up and running efficiently.
When it comes to ordering the right tractor parts, compatibility with your specific model and year is crucial. Here's how you can make the right choice:
Start by carefully identifying the model of your tractor. Look for parts that include a detailed list of compatible tractor models. This information is usually clearly stated to help you determine if a part will fit your machine.
Pay close attention to any specific years that are mentioned. Some parts are designed for certain model years due to design tweaks and changes made by manufacturers. Ensuring that your tractor's year matches those listed can prevent compatibility issues.
Most part listings include a 'Fits Models' section. This list is invaluable for making sure you're selecting a part that will seamlessly integrate with your tractor.
If you’re unsure, consult a professional or a trusted dealer. They can offer expert advice and may even have access to cross-reference systems that can confirm part compatibility.
Before finalizing your order, double-check the model and year once more to ensure everything aligns. This simple step can save you from unnecessary hassle and return processes.
Following these steps will help you select the right parts the first time, ensuring your tractor remains in top working condition without unnecessary delays.
