Description:
Aeration is vitally important for healthy turf, and it’s also an opportunity to expand your services. A new tool to tackle aeration with more efficiency, the stand-on Aer Storm™ aerator allows you to get more done than ever before. Designed and engineered for long-lasting durability, improved productivity, and all-day comfort, it’s time to take on your next challenge with the next generation of aeration.
Features:
Easy Depth Adjustment and Engagement: Featuring a simple and intuitive depth selection pin with an easy-grip rubber knob, select aerating depths of 1" to 4" in 1/2" increments to meet the needs of each specific property. Hydraulic tine engagement, via a convenient foot-activated switch, allows you to keep your hands on the steering controls for maximum productivity and safety. Plus, a tine activation switch on the instrument panel prevents accidental engagement or disengagement while working or transporting.
Accessible Controls: Incredibly easy to use, its ergonomic drive control levers make it a cinch to maneuver and allows you to get more done.
Stay in the Loop: A full-featured and easy-to-view instrument panel keeps you informed of exactly what you need to know.
Experience an Unmatched, Ultra-Comfortable Ride: A spacious operator platform featuring suspension and a padded, bolstered cushion ensures a smooth, comfortable ride all day long.
More Uptime: Removable cushion and lower panel allow quick and easy service access to the hydro tank and tines.
Solid Design for Years of Dependable Service: Heavy-duty, durable construction ensures years of dependable service and worry-free productivity.
Huge Power, up to 23 Hp: 23 hp Kohler® Command Pro® engine packs the power you need alongside exceptional efficiency and dependable performance.
Specifications
Product Specification: AerStorm
Model Number: AS30-23CV
Type: Plug-style aeration. Mid/under-belly mount.
Aerating Width: 30 in.
Aerating Depth/Adjustment: 1 in. to 4 in. in 1/2 in. increments. Simple and intuitive depth selection pin with easy-grip rubber knob.
Tines: 48 self-cleaning, replaceable, steel coring tines
Tine Activation & Pressure: Hydraulic tine engagement (raise and lower) via a foot-activated switch. Tine activation switch on the instrument panel prevents accidental engagement/disengagement while working or transporting. Adjustable hydraulic down-pressure helps to penetrate even the hardest and driest soils to ensure effective aeration performance in all conditions.
Engine Specification
General Type: Heavy-duty Industrial/commercial
Brand: Kohler Command Pro
Model: CV732
Horsepower: 23.5 HP @ 3600 RPM
Torque: 40.3 ft. lb. (peak)
Type: 4 cycle gas, twin-cylinder, air-cooled, OHV, vertical shaft engine
Displacement: 747 cc (45.6 cu.in.)
Cylinders: 2 cast-iron sleeves
Governor: Mechanical type governor with variable speed control set at 3600 RPM (±100 RPM), idle set at 1800 RPM (±150 RPM)
Air Intake Group: Large capacity 2-stage canister air filter
Exhaust Group: Single exhaust canister muffler
Fuel Pump Group: Integral fuel pump with Inline fuel filter, internal fuel line vent; float feed; two-barrel, adjustable idle, afterfire solenoid.
Oil Pump Group: Full pressure lube, with full-flow filter, 2-quart oil capacity
Starter/Electrical/Charging System: "12-volt ""maintenance-free"" sealed battery with alternator, solid-state ignition with key start. 15 amp charging system, regulated."
Engine Deck Thickness: 1/4" steel
Fuel Tank: 5.5 gallons (20.8 liters) tank with molded-in cup holder
Drive Wheels/Tires: 18 x 6.5 - 8 four-ply pneumatic tubeless, radius edge
Caster Wheels: 13 x 6.5 - 6 Flat-Free (semi-pneumatic)
Brakes: Lever-actuated linkage to brakes on both drive wheels
Operator Platform: Heavy gauge steel with extruded star pattern for no-slip footing. Dual adjustable suspension for operator comfort level preference.
Operator Comfort Pad: Large heavily-bolstered operator cushion can be easily removed without tools for access to hydraulics
Drive System Type: Hydro drive with two variable displacement pumps and two cast-iron high-torque wheel motors for independent control of each drive wheel
Hydro Pumps: Two Hydro-Gear PG Series 10cc pumps with dump valves for movement without running the engine; one cooling fan
Drive Wheel Motors: Two Parker TG 14.5 cu. inch cast-iron high-torque wheel motors
Hydro Fluid Cooling Group: 3.0 qt. capacity cooling reservoir; uses SAE 20W50 fluid and 10-micron filter
Steering/Travel Control: Twin lever steering control with individual control to each wheel
Dump Valves: Allows for movement without the engine running
Axles: 1.25" heavy-duty, straight motor shafts
Wire Harness: 14 and 16 gauge wire
Safety Group: Footplate-actuated operator presence system interlock to engine kill
Forward Speed Range: 0 up to 7.0 mph
Reverse Speed Range: 0 up to 3.0
Year: 2023
Manufacturer: Scag Power Equipment
Model: AS30-23CV
Style: Stand On
Price: Call for Price
Deck Size Discharge Type Engine: Engine Manufacturer Kohler Command Pro Horse Power 23.5 HP @ 3600 RPM Engine Type CV732 Displacement General Transmission Wheel Size Fuel Capacity 5.5 gal. (20.8 L)
Width
Weight
Height
Length
0 Inch
0 Gram
0 Inch
0 Inch
Read more less
